Yamaha TZR125 Engine Parts Top End



Yamaha TZR125 Small End Bearing

Yamaha TZR125 Small End Bearing

Small End Bearing To Fit The Yamaha TZR125 code on the cylinder should be 2RH00 OR 3MBO OR 4 FU

This Small End Bearing Is 19.50mm Wide And Will Fit All Mitaka Pistons Either 3MB Or 4FU Cylinders.

If you are using a Genuine Yamaha Piston Then Best Check The Space Between G-Pin To See As Some Genuine Yamaha Pistons Need A 17.50mm Wide Small End Bearing

This Small End Bearing Will Not Fit The Wossner 4FU Piston.


Price: 4.50 (5.40 Including VAT at 20%)



Quantity:






Yamaha TZR125 Piston Kit

Yamaha TZR125 Piston Kit

Piston kit contains piston, piston rings, gudgeon pin and 2 circlips

This piston kit is to fit the Yamaha TZR125 code on the cylinder should be 2RH00, Std Bore Is 56.40mm

The Yamaha TZR125 Engine Has A Std Bore Of 56.40mm. The Cylinder Is Fitted With A Cast iron Sleeve From The Factory And Is Re-boreable So Please Check Your Size Before Ordering The Piston.

You Can Go All The Way Up To 59.15mm But After Around 57.00mm The Cylinder Head Gasket And Cylinder Head May Need To Be Opened Out To Avoid The Piston Hitting Them.

Piston Kit Made By Mitaka

Use Small End Bearing 19.50 mm Wide

Please Chose Size



Price: 39.45 (47.34 Including VAT at 20%)



Quantity:






Yamaha TZR125 R Piston Kit Mitaka

Yamaha TZR125 R Piston Kit Mitaka

Mitaka Piston Kit To Fit The Yamaha TZR 125 4DL With The Cylinder Number 3MB 00

Piston kit contains piston, piston rings, gudgeon pin and 2 circlips.

Please check the code on the cylinder should be 3MB 00 And A Standard Bore Size Of 56.00mm

Use Small End Bearing 19.50 mm Wide

The Yamaha TZR125 Engine Has A Std Bore Of 56.00mm. The Cylinder Is Fitted With A Cast iron Sleeve From The Factory And Is Re-boreable So Please Check Your Size Before Ordering The Piston.

You Can Go All The Way Up To 59.15mm But After Around 57.00mm The Cylinder Head Gasket And Cylinder Head May Need To Be Opened Out To Avoid The Piston Hitting Them.

Please Chose Size



Price: 39.45 (47.34 Including VAT at 20%)



Quantity:






Customer Reviews

  great speedy, well priced service  ordered the parts and they arrived within a couple of days. great service, well packaged and the correct item too which is always a bonus lol   (17/03/2016) -
Our Reply: Thank you for your Review



Yamaha TZR125 R Piston Kit Wossner

Yamaha TZR125 R Piston Kit Wossner

Wossner Piston Kit To Fit The Yamaha TZR125R All Years With The Cylinder Number 3MB 00 And 3MBP 00

Piston kit contains piston, piston rings, gudgeon pin and 2 circlips.

Please check the code on the cylinder should be 3MB 00 And A Standard Bore Size Of 56.00mm

Use Small End Bearing 19.50 mm Wide

The Yamaha TZR125R Engine Has A Std Bore Of 56.00mm. The Cylinder Is Fitted With A Cast iron Sleeve From The Factory And Is Re-boreable So Please Check Your Size Before Ordering The Piston.

You Can Go All The Way Up To 58.00mm With These Wossner Pistons But After Around 57.00mm The Cylinder Head Gasket And Cylinder Head May Need To Be Opened Out To Avoid The Piston Hitting Them.

Please Chose Size



Price: 69.99 (83.99 Including VAT at 20%)



Quantity:






Genuine Yamaha TZR 125 2RH 3MB Small End Bearing

Genuine Yamaha TZR 125 2RH 3MB Small End Bearing

Small End Bearing To Fit The Yamaha TZR125 2RH and 3MB This Is A Genuine Yamaha Part.

The Size Is 16-21-19.5

This Relates To The Gudgeon Pin Or Wrist Pin Being 16mm OD, The Inside Of The Connecting Rod Being 20mm And The Bearing Being 19.50mm Wide.

Genuine Yamaha Part Number 93310-316D5 Replaces Part Number 93310-316H7


Price: 17.83 (21.40 Including VAT at 20%)


Quantity:






Yamaha TZR125R Small End Bearing For Wossner 4FU Type Piston

Yamaha TZR125R Small End Bearing For Wossner 4FU Type Piston

Small End Bearing To Fit The Yamaha TZR125R With The Wosner Piston Kit For The 4FU Cylinder.

This Small End Bearing Is 17.50mm Wide And Will Fit The Wossner 4FU Piston And Some Genuine Yamaha Pistons .

If You Are Using A Genuine Yamaha Piston Then Best Check The Space Between G-Pin To See As Some Genuine Yamaha Pistons

Need This 17.50mm Wide Small End Bearing

This Small End Bearing Will Not Fit The Mitaka Pistons, OR The Wossner, Mitaka Dome Top 3MB Piston.


Price: 4.50 (5.40 Including VAT at 20%)



Quantity:






Yamaha TZR125 Top End Gasket Kit

Yamaha TZR125 Top End Gasket Kit

Quality top end gasket kits all the gaskets required to strip and rebuild your cylinder/ top end.

This gasket kit is to fit the Yamaha TZR125 code on the cylinder should be 2RH00
Price: 11.50 (13.80 Including VAT at 20%)



Quantity:






Yamaha TZR125 2RH Top Gasket Set

Yamaha TZR125 2RH Top Gasket Set

Top End Gasket Kit For The Yamaha TZR125 2RH Model.

This gasket kit it to fit the Yamaha TZR125 code on the cylinder should be 2RH

This Kit Is Made In Italy By Athena And Is A Better Quality One Than The Budget One We Sell Which Is Made In Taiwan. "Why is it better i hear you say" Well the gaskets are made from the same materiel & in the same factory as the original Yamaha ones, the gasket material is better than the Taiwanese one and fits much nicer.
Price: 14.25 (17.10 Including VAT at 20%)


Quantity:






Yamaha TZR125 Mitaka Piston Kit For Plated Bore 4FU

Yamaha TZR125 Mitaka Piston Kit For Plated Bore 4FU

Mitaka Piston kit it to fit the Yamaha TZR125R code on the cylinder should be 4FU 00 and the piston has a flat top to it.

Piston kit contains piston, piston rings, gudgeon pin and 2 circlips

Use Small End Bearing 19.50 mm Wide
Price: 45.25 (54.30 Including VAT at 20%)



Quantity:






Yamaha TZR125 Wossner Piston Kit For Plated Bore 4FU

Yamaha TZR125 Wossner Piston Kit For Plated Bore 4FU

Wossner Piston kit it to fit the Yamaha TZR125R 55.94mm code on the cylinder should be 4FU 00 and the piston has a flat top to it.

55.94mm Piston

Piston kit contains piston, piston rings, gudgeon pin and 2 circlips

Must Use Small End Bearing 16x21 by 17.50 mm Wide
Price: 69.65 (83.58 Including VAT at 20%)



Quantity:






Yamaha TZR125R Top End Gasket Set

Yamaha TZR125R Top End Gasket Set

Quality top end gasket kits all the gaskets required to strip and rebuild your cylinder/ top end.

This gasket kit it to fit the Yamaha TZR125R code on the cylinder should be 4FU 00 .
Price: 11.50 (13.80 Including VAT at 20%)



Quantity:






Yamaha TZR125R Top End Gasket Kit Athena

Yamaha TZR125R Top End Gasket Kit Athena

Top Gasket Kit For The Yamaha TZR125R 4FU / 4DL Model.

This gasket kit it to fit the Yamaha TZR125R code on the cylinder should be 4FU 00 .

This Kit Is Made In Italy By Athena And Is A Better Quality One Than The Budget One We Sell Which Is Made In Taiwan. "Why is it better i hear you say" Well the gaskets are made from the same materiel & in the same factory as the original yamaha ones, the gasket material is better than the Taiwanese one and fits much nicer.

Made In Italy

Bigger Photo Here
Price: 16.99 (20.39 Including VAT at 20%)



Quantity:






Customer Reviews

  good item  ordered the parts and they arrived within a couple of days. great service, well packaged and the correct item too which is always a bonus lol   (17/03/2016) -
Our Reply: Thank you for your Review



Yamaha TZR125R Base Gasket

Yamaha TZR125R Base Gasket

Replacement Base Gasket To Fit The TZR125R 4FU / 4DL Model

Code On The Side Of The Cylinder Should Be 4FU 00 Or 3MB0

Made By Athena In Italy

Replaces Yamaha Part Number 4FU 1135100


Price: 3.90 (4.68 Including VAT at 20%)


Quantity:




People who bought this item also bought:
1. Yamaha DT125R Head Gasket Athena
2. Yamaha Power Valve Bush O-Ring 93210-27778 TZR125 UK TZR250 Etc
3. Yamaha Power Valve Service Kit DT125R, TZR125 Etc



Yamaha TZR125R Reed Valve Gasket

Yamaha TZR125R Reed Valve Gasket

Reed Valve Gasket To Fit The Yamaha TZR125 2RK TZR125R

Qualty Part Made By Athena

Replaces Yamaha Part Numbers 1KT1362101 1KT1362100
Price: 2.50 (3.00 Including VAT at 20%)


Quantity:






Yamaha TZR125R Genuine Base Gasket

Yamaha TZR125R Genuine Base Gasket

Genuine Yamaha TZR125R Base Gasket

Yamaha Part Number 4FU1135100
Price: 14.19 (17.03 Including VAT at 20%)


Quantity:






Yamaha TZR125R Head Gasket Genuine Yamaha

Yamaha TZR125R Head Gasket Genuine Yamaha

Genuine Yamaha TZR125R Head Gasket

Fits TZR125R 4FU / 4DL Model, Code On The Side Of The Cylinder Should Be 4FU 00 Or 3MB0

Yamaha Part Number 3BN1118102
Price: 22.40 (26.88 Including VAT at 20%)


Quantity:




People who bought this item also bought:
1. Yamaha Power Valve Service Kit DT125R, TZR125 Etc
2. Yamaha DT125R Base Gasket
3. Yamaha Water Pump Seal



Yamaha TZR125R Cylinder Head Stud

Yamaha TZR125R Cylinder Head Stud


Yamaha TZR125R Cylinder Head Stud Genuine Yamaha Part Number 90116-08394

This Part Will Also Fit The Following Model Bikes.

Yamaha DT125, Yamaha DT125 MX, Yamaha DT125 LC, Yamaha DT125R, Yamaha DT175, Yamaha DT200R, Yamaha IT200, Yamaha RD125LC, Yamaha TDR125, Yamaha TY250, Yamaha TY250R, Yamaha TZR125, Yamaha TZR250R,Yamaha WR200, Yamaha WR500, Yamaha YFS200 BLASTER, Yamaha YFZ350 BANSHEE, Yamaha YZ80 1993-2001, Yamaha YZ85 2002-2006, Yamaha YZ125 1987-1999, Yamaha YZ250 198-2006, Yamaha YZ490.

Sorry There Is No Spare Parts Associated With This Product


Price: 3.50 (4.20 Including VAT at 20%)


Quantity:




People who bought this item also bought:
1. Yamaha Power Valve Service Kit DT125R, TZR125 Etc
2. 90116-08042 Yamaha DT125R Cylinder Exhaust Stud
3. Yamaha DT125R Sprocket Shaft Oil Seal



Yamaha TZR125R Cylinder Exhaust Stud

Yamaha TZR125R Cylinder Exhaust Stud


Yamaha TZR125R Cylinder Exhaust Stud Genuine Yamaha Part Number 90116-08042

This Part Will Also Fit The Following Model Bikes.

Yamaha DT125, Yamaha DT125 MX, Yamaha DT125 LC, Yamaha DT125R, Yamaha DT175, Yamaha DT200R, Yamaha IT200, Yamaha RD125LC, Yamaha TDR125, Yamaha TY250, Yamaha TY250R, Yamaha TZR125, Yamaha TZR250R,Yamaha WR200, Yamaha WR500, Yamaha YFS200 BLASTER, Yamaha YFZ350 BANSHEE, Yamaha YZ80 1993-2001, Yamaha YZ85 2002-2006, Yamaha YZ125 1987-1999, Yamaha YZ250 198-2006, Yamaha YZ490.

Sorry There Is No Spare Parts Associated With This Product


Price: 2.86 (3.43 Including VAT at 20%)


Quantity:




People who bought this item also bought:
1. Yamaha Power Valve Service Kit DT125R, TZR125 Etc
2. 90116-08394 Yamaha DT125R Cylinder Head Stud
3. Yamaha DT125R Sprocket Shaft Oil Seal



Yamaha TZR125R Small End Bearing

Yamaha TZR125R Small End Bearing

Small End To Fit The Yamaha TZR125R 4FU

Small End Is 16x21 by 17.50mm Wide


Price: 4.50 (5.40 Including VAT at 20%)



Quantity:






Yamaha TZR125 Piston C-Clips

Yamaha TZR125 Piston C-Clips

Pair Of C-Clips For The TZR125 Piston (price is for a pair IE 2 c-clips)
Price: 1.90 (2.28 Including VAT at 20%)



Quantity:






Yamaha TZR 125 Power Valve Seal

Yamaha TZR 125 Power Valve Seal

Power Valve Seal To Fit The Yamaha TZR 125 TZR125R TZR 125 2RH Fits All Years.

Number 19 on Diagram above

Price Is For 1 Seal

Genuine Yamaha Parts Number 93108-23010
Price: 4.99 (5.99 Including VAT at 20%)


Quantity:






Yamaha TZR125 Power Valve Bush O-Ring UK Bike Only

Yamaha TZR125 Power Valve Bush O-Ring UK Bike Only

Power Valve Bush O-Ring To Fit The Yamaha TZR 125 2RH UK Bike Only With Cylinder Code 2RH

Number 20 on Diagram above

Price Is For Qty 1 But 2 Are Required

Replaces Yamaha Part Numbers 93210-27778


Price: 2.99 (3.59 Including VAT at 20%)


Quantity:






Yamaha TZR125 Power Valve Bush O-Ring TZR125R R

Yamaha TZR125 Power Valve Bush O-Ring TZR125R R

Power Valve Bush O-Ring To Fit The Yamaha TZR125R With Cylinder Code 3MB, 3MBP 4FU.

Number 20 on Diagram above

Price Is For Qty 1 But 2 Are Required On The TZR 125RR

Replaces Yamaha Part Numbers 93210-30734 And 93210-30640


Price: 2.99 (3.59 Including VAT at 20%)


Quantity:




People who bought this item also bought:
1. Yamaha DT125R Head Gasket Athena
2. Yamaha DT125R Small End Bearing
3. Yamaha DT125R Piston Kit Mitaka Kit



Yamaha TZR125 Power Valve Service Kit TZR125R R

Yamaha TZR125 Power Valve Service Kit TZR125R R

Yamaha TZR125 Power Valve Service Kit, Fits TZR125R With Cylinder Code 3MB, 3MBP 4FU 3MB-P

If You Are Getting Oil Splurge Out Of Your Power Valve Area Chances Are Your Power Valve Seal And O-Rings Have Gone Hard. They Are Subject To A Lot Of Heat And Spent Two Stroke Oil So Do Get A Very Hard Time, This Can Lead To Exhaust Gases Escaping That Can Change How The Engine Runs.

We Have Put Together This Kit That Contains 2 O-Rings (one for each end of the bushes) And 1 Shaft Seal That Fits Into The Left Hand Bush.


Price: 10.96 (13.15 Including VAT at 20%)


Quantity:




People who bought this item also bought:
1. Yamaha DT125R Thermostat Housing Gasket
2. 90116-08042 Yamaha DT125R Cylinder Exhaust Stud
3. 90116-08394 Yamaha DT125R Cylinder Head Stud



Yamaha TZR125 Power Valve Service Kit TZR125 2RH UK Bike

Yamaha TZR125 Power Valve Service Kit TZR125 2RH UK Bike

Yamaha TZR125 UK Bike Power Valve Service Kit, Fits Only Yhe UK TZR 125 With Cylinder Code 2RH

If You Are Getting Oil Splurge Out Of Your Power Valve Area Chances Are Your Power Valve Seal And O-Rings Have Gone Hard. They Are Subject To A Lot Of Heat And Spent Two Stroke Oil So Do Get A Very Hard Time, This Can Lead To Exhaust Gases Escaping That Can Change How The Engine Runs.

We Have Put Together This Kit That Contains 2 O-Rings (one for each end of the bushes) And 1 Shaft Seal That Fits Into The Left Hand Bush.


Price: 10.96 (13.15 Including VAT at 20%)


Quantity:






Yamaha TZR125 NGK Spark Plug

Yamaha TZR125 NGK Spark Plug

Standard Spark Plug BR9ES
Price: 3.83 (4.60 Including VAT at 20%)


Quantity:




People who bought this item also bought:
1. Yamaha DT125R Namura Piston Kit
2. Yamaha DT125R Small End Bearing
3. Motul Motocool Expert Engine Coolant



Yamaha TZR125 NGK Racing Spark Plug

Yamaha TZR125 NGK Racing Spark Plug

NGK Racing Spark Plug BR9EG
Price: 7.02 (8.42 Including VAT at 20%)


Quantity:




People who bought this item also bought:
1. Aprilia RS50 Clutch Lever 2006-2012 Carbon Look
2. Cagiva Mito, Planet,Raptor,Supercity Bearing And Seal Kit Koyo
3. Cagiva Mito, Planet,Raptor,Supercity Cylinder Kit Dome Top Piston 2 Piston Rings



Customer Reviews

  this is the one  I only ever fit this plug in my Mito evo 1   (28/08/2012) Jason - swadlincote



Yamaha TZR125 NGK IRIDIUM Spark Plug

Yamaha TZR125 NGK IRIDIUM Spark Plug

NGK IRIDIUM Spark Plug Offers,Enhanced Igniton Efficiency, Better Acceleration,Faster Starting & Smother, Running, Longer Life
Price: 13.12 (15.74 Including VAT at 20%)


Quantity:




People who bought this item also bought:
1. KTM125 SX Prox Piston Kit 2007-2016
2. KTM 125 SX Crankshaft
3. KTM 125 Full Gasket Set 2007-2014



NGK Spark Plug Cap Black

NGK Spark Plug Cap Black

NGK Spark Plug Cap For Use With Screw On Terminal Post Black

Suitable For Both 2T And 4T Engines

LB05E Black
Price: 2.88 (3.46 Including VAT at 20%)



Quantity:




People who bought this item also bought:
1. S410485010018 RD350YPVS Reed Valve Gasket
2. Motul Motocool Expert Engine Coolant
3. Oil Pipe 2mm x 5mm Clear



NGK Spark Plug Cap Black No Terminal Post

NGK Spark Plug Cap Black No Terminal Post

NGK Spark Plug Cap For Use Without Screw On Terminal Post Black

Suitable For Both 2T And 4T Engines

LB05F Black
Price: 4.83 (5.80 Including VAT at 20%)



Quantity:






NGK Spark Plug Cap Racing Red

NGK Spark Plug Cap Racing Red

Racing Spark Plug Cap Rubber Sheathed For Added Water Proofing

Red

For Use With Screw On Terminal Post Only


Price: 5.32 (6.38 Including VAT at 20%)



Quantity:




People who bought this item also bought:
1. Aprilia RS125 Front Brake Pads 1992-2005
2. Motul 710 2T Engine Oil
3. Buzzeti Piston Pin Remover Pliers



Customer Reviews

    great cap   (10/07/2014) -





PJ Motorcycle Engineers - Specialists in 2 Stroke Engines


Aprilia RS125 Carb Main Jet Dellorto 6mm
Aprilia RS125 Carb Main Jet Dellorto 6mm

4.68
5.62
find out more

Aprilia RS125 Moto RRT Oil Filler Plug Alloy Type
Aprilia RS125 Moto RRT Oil Filler Plug Alloy Type

5.99
7.19
find out more

Aprilia RS125 Bore Kit Rotax 122 Cylinder Kit
Aprilia RS125 Bore Kit Rotax 122 Cylinder Kit

169.36
203.23
find out more


PJME Home
About Us
Contact Us
Links Page
News
General Shipping & Returns Information
Privacy Policy
Online Security
Cagiva 125
Yamaha RD350 LC
Yamaha RD350 YPVS
Cylinder Re-Sleeving
Cylinder Re-Coating
Cylinder Re-Boring
Crankshaft Rebuilding
Engine Rebuilding
Cylinder Packing
Engine Packing
Aprilia RS125
Home | About Us | Shipping & Returns | Terms & Conditions | Contact Us | Site Map | Search | Links & Resources

© Copyright PJME 2008-2013

Actinic Web Design maintained by Hanson Web Design
